ASTM A105 SS Flanged Gate Valve, 1 Inch, 150LB

Name: ASTM A105 SS Flanged Gate Valve, 1 Inch, 150LB
SKU: LV 14 CGV 07
Availability: InStock
Rating: 5 (1 reviews)

Key Specifications / Features

Model No.: LV 14 CGV 07 Hits: 867

China ASTM A105 SS Gate Valve: 1 Inch, 150LB Gate Valves, Stainless Steel ASTM A105, API 602, API 598, Hard Seat, Flanged RF, Rising Stem, Hand Wheel.

Request a quote Share

Tags: 1 Inch, Handwheel, Flanged Ends, ASTM A105, API 602, API 598, PN20, DN25, 150LB, Bolted Bonnet,

Previous: A216 Alloy Steel Gate Valve, 18 Inch, 900LB, BW
Next: Handwheel LTCS Gate Valve, DN20, SW X FNPT

Detail Information

Type: Staniless Steel Gate Valve.

Make: Approved.

Size: 1 Inch (DN25).

Pressure: 150LB (PN20).

Flanged End Raised Face as per ANSI B16.5.

Design and Test Standards: API 602, API 598.

Body Material: ASTM A105.

Stem Material: 13% Cr. SS.

Trim Material: 13% Cr. SS.

Seat Material: 13% Hard Faced Cr. SS.

Seat Ring Material: 13% Cr. Hard Face.

Wedge Disc Material: ASTM A216 Gr.WCB A276 420.

Bolting Material: ASTM A193 Gr. B7 & A 194 Gr.2H.

Bore Design: Regular Bore Design.

Feature: Rising Stem.

Operator: Hand Wheel.

Style: Bolted Bonnet, Bolted Gland, Solid Wedge. Renewable Seats with Stem Protector, OS&Y.

Service Fluid: Refined Petroleum Products (Gasoline, Diesel, Kerosene, Jet A-1, LDO and Furnace Oil).
